Marantz PM-6007 Özellikleri

Features

Channels 2

Current Feedback Topology •

Phono EQ: Standard / Marantz Musical / Marantz Musical Premium • / - / -

Digital in: USB-B / optical / coaxial / USB-A - / 2 / 1 / -

Sample Rate digital In 192 kHz / 24-bit

DAC chip AK4490

HDAM version SA3

Power Transformer: Toroidal / El • / -

High Grade Audio Components •

Customised Components •

Symmetric PCB Layout -

Aluminium extrusion heat sink •

Copper plated chassis -

Balance / Bass / Treble / Loudness • / • / • / -

Other

Marantz Musical Digital Filtering •

Linear Drive Power Supply •

Liniear volume control •

BI-AMP and Multichannel option -

Shottky diodes •

Source Direct •

Power Amp direct -

Inputs / Outputs

Audio Inputs 5

Digital in: USB-B / optical / coaxial / USB-A - / 2 / 1 / -

Phono Input: MM / MC • / -

Audio Outputs 1

Balanced In / Out - / -

Pre-out / Main-in Subwoofer / -

Power Amp Direct IN -

Gold Plated Cinch •

Speaker A / B •

Speaker Terminals: Metal (Gold) Screw

Number of terminals 4

D-Bus •

Headphone Out

Specifications

Power Output (8 / 4 Ohm RMS) 45 W / 60 W

Frequency Response 10 Hz - 70 kHz

Total Harmonic Distortion 0.08 %

Damping Factor 100

Input Sensitivity: MM 2.2 mV / 47 kOhm

Input Sensitivity: MC –

Signal to Noise Ratio: MM/MC 83 dB / -

Input Sensitivity: High level 200 mV / 20 kOhm

Input Sensitivity: Balanced High level -

Signal to Noise Ratio: High level 102dB(2V input)

General

Available colors: Gold / Silver / Black / Silver-Gold - / - / • / •

Metal Front Panel •

Power Consumption in W 155

Standby Consumption in W 0.3

Auto Power off •

Detachable Power Cable •

Remote Control RC004MCD

System Remote Function •

Maximum Dimensions (W x D x H) in cm 440 x 370 x 105cm

Weight in kg 7.8kg

Carton Maximum Dimensions (W x D x H) in cm 517 x 468 x 189

Carton Weight (incl. product) in kg 9.7
