Marantz CD-6007 Özellikleri

Features

CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC • / • /- / • / • /-

CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta data - / - / • / • / •

HDAM version HDAM+HDAM SA2

Power Transformer: Toroidal / El - / •

High Grade Audio Components •

Customised Components •

Symmetric circuit layout •

Copper plated chassis -

Extra metal plate for chassis strengthing •

Digital out off / Audio EX Mode • / -

Headphone: Standard / Buffer / Current feedback - / • (HDAM-SA2) / -

Other

Selectable filter: CD / SA-CD / DAC-Mode • / - / -

Marantz Musical Mastering •

Separated rectifier circuit for analogue and digital circuitry •

Display: Dimmer / Off • / •

Playback

Program Play (CD) 25

Repeat •

Random Play •

Inputs / Outputs

Analogue Out (Cinch) 2ch

Balanced Out -

Digital Optical In / Out - / 1

Digital Coaxial In / Out - / 1

Gold plated Cinch •

USB Audio (front) / Made for iPod / Made for iPhone • / - / -

USB-A: FLAC / WAV / AIFF / ALAC / DSD •

D-Bus •

Headphone Out •

Headphone Volume Control

Specifications

Mechanism JTL-101Y

D/A Conversion Multi-bit, Delta-Sigma

DAC IC AK4490

Digital Filter AK4490

Noise Shaper AK4490

Low Pass Filter stage HDAM

Output Buffer HDAM SA2

Headphone amp HDAM-SA2buffer+OPAMP

CDDA AUDIO

Frequency Response 2 Hz - 20 kHz

Dynamic Range 100 dB

Signal to Noise Ratio 110 dB

Total Harmonic Distortion 0.002%

Channel Separation 98 dB

General

Available colors: Gold / Silver / Black / Silver-Gold - / - / • / •

Metal Front Panel •

Remote Control RC004PMCD

Power Consumption in W 32

Standby Consumption in W 0.3

Auto power off •

Detachable Power Cable •

Maximum Dimensions (W x D x H) in cm 440 x 340 x 105cm

Weight in kg 6.5kg

Carton Maximum Dimensions (W x D x H) in cm 517 x 468 x 189cm

Carton Weight (incl. product) in kg 8.8kg
